Wheel Encoder Kit

Producto nº: AD9616
Tu precio: US$17,95
No. de artículos en existencia: 2
Disponibilidad: En existencia
  • Vendedor: SPARKFUN.COM

Descripción:

This is the Wheel Encoder Kit from DAGU, a simple add-on to any wheeled robot that can help measure the speed or distance the chassis travels. Each wheel encoder kit consists of two neodymium 8-pole magnets with rubber hubs and two hall-effect sensors terminated with 150mm cables and 3-pin female servo headers. These wheel encoders require a supply voltage of 3-24V with a supply current of 4mA.

Features:

  • Supply Voltage: 3-24V
  • Supply Current: 4mA per sensor
  • Output Voltage: 26V Max
  • Output Current: 25mA Continuous

Documents:

Para más detalles ver el siguiente enlace: www.sparkfun.com/products/12629
